Specifications

Dimension (W x H x D)

132.6 x 482.6 x 296.5 mm

Weight

14kg (31 lbs)

Operating Temperature

-30 ~ +60 °C

Frequency

136-174 MHz
403 - 470 MHz

Channel Spacing

12.5 kHz / 25 kHz

Frequency Stability

± 0.5 ppm

Power Output

1-40 W

4FSK Digital Modulation

12.5kHz Data Only: 7K60FXD
12.5kHz Data & Voice: 7K60FXE

Conducted/Radiated Emission (TIA603D)

-36 dBm < 1GHz
-30 dBm > 1GHz

Digital Vocoder Type

AMBE+2™

Digital Protocol

ETSI TS 102 361 -1,-2,-3

Frequencies

136-174 MHz
403 - 470 MHz

Channel Spacing

12.5 kHz
25 kHz

Frequency Stability

±1.5ppm

Digital Sensitivity

5% BER : 0.3uV

Intermodulatioin TIA603C ETS

75 dB
70 dB

Audio Distortion @ Rated Audio

3% (typical)

Hum and Noise

-40 dB @ 12.5 kHz
-45 dB @ 25 kHz

Audio Response

+1, -3 dB

Conducted Spurious Emission

-57dBm

TIFF (Time To First Fix) – Cold Start

< 60 seconds

TIFF (Time To First Fix) – Hot Start

< 10 seconds

Horizontal Accuracy

< 5 meters

Verison

Supports Bluetooth® 2.1 + EDR Specification

Range

Class 2, 10 meters

Profiles Supported

Bluetooth Headset Profile (HSP), Serial Port Profile (SPP), Motorola fast push-to-talk

Device Supported

Radio supports 1 Bluetooth audio accessory and 1 Bluetooth data device simultaneously

Operating Temperature

-30°C to +60°C

Storage Temperature

-40°C / +85°C

Thermal Shock

Per MIL-STD

Humidity

Per MIL-STD

ESD

IEC 61000-4-2 Level 3

Dust and Water Intrusion

IEC60529 – IP67

Packaging test

MIL-STD 810F and G
